Main function
|
Cooling |
YES |
|
Heating |
YES |
|
Fresh Air |
YES |
|
Auto Control |
YES |
|
Ventilation |
YES |
|
Power lost memory |
YES |
|
Error alarm |
YES |
|
Air flow regulation |
7-grade PWM |
|
Demist |
YES |
Application:
YUTONG Heavy Industries, XUGONG Machinery
|
Power supply |
DC12/24V |
|
Power consumption |
3W |
|
Dimensions |
170X60X95mm |
|
Input |
1) ACC power(battery) 2) A/C power 3) Backlight power 4) Air inlet temp. sensor 5) Defrost sensor |
|
Output |
1) Evaporator fan output 2) Warming output 3) Cooling output
|
|
Display |
LED |
|
Ambient temperature |
-40℃—85℃ 5%－95%RH Non-condensing |
|
Storage temperature |
-40℃—90℃ 5%－95%RH Non-condensing |
|
Protection |
IP43 |
|
EMC |
EN50081&EN50082-2 |
|
Security level |
Applied to EN61010-II, Pollution degree: II |
|
Weight |
230g |
Dimension drawing
.png)
.jpg)
.png)
